Haugen HIRG 84 - 84" Bucket Width, 1,330 lbs Weight, 11 Cast Tooth w/ replaceable Tip, Industrial Rod Grapple for Skid Steer
![Haugen HIRG 84 - 84" Bucket Width, 1,330 lbs Weight, 11 Cast Tooth w/ replaceable Tip, Industrial Rod Grapple for Skid Steer Haugen HIRG 84 - 84" Bucket Width, 1,330 lbs Weight, 11 Cast Tooth w/ replaceable Tip, Industrial Rod Grapple for Skid Steer](https://cdn11.bigcommerce.com/s-vtryl8/images/stencil/original/products/1130528/10703077/image36__45480.1712543869.jpg?c=2)
Haugen HIRG 84 - 84" Bucket Width, 1,330 lbs Weight, 11 Cast Tooth w/ replaceable Tip, Industrial Rod Grapple for Skid Steer
Haugen HIRG 84 - 84" Bucket Width, 1,330 lbs Weight, 11 Cast Tooth w/ replaceable Tip, Industrial Rod Grapple for Skid Steer
Introducing the Haugen HIRG 84 - 84" Bucket Width, 1,330 lbs Weight, 11 Cast Tooth w/ replaceable Tip, Industrial Rod Grapple for Skid Steer. Designed to handle rocks and brush with ease, this industrial rod grapple boasts independent twin grapples and industrial grade cylinders. With features such as weld-on tooth bar with replaceable teeth and 3 inch spacing between the rods, you can be assured that your job is handled efficiently. The heavy duty tines are made of 1' x 1 1.2' curved flat bar and are equipped with a double cylinder grapple with independent claws plus industrial 2.5" x 10" cylinders for extra durability. Your grapple is also treated to a powder coat finish for added protection. But don’t let size deter you since multiple sizes are available from 76” to 84” including global style mounts and other tractor mounts for versatility. Nothing beats the Haugen HIRG 84 - 84" Bucket Width, 1,330 lbs Weight, 11 Cast Tooth w/ replaceable Tip, Industrial Rod Grapple for Skid Steer in quality and reliability order yours today.
Industrial Rod Grapple
The Industrial rod grapple is designed for handling rocks and brush. It has independent twin grapples and industrial grade cylinders. Available sizes are 76",and 84"
Features
- Weld-on Tooth bar with replaceable teeth
- All pivot points are greaseable
- Excellent hose routing and abrasion sleeves to protect the hoses from damage
- 3 inch spacing between the rods
- Heavy duty Tines are made of 1' x 1 1.2' curved flat bar
- Double cylinder grapple with independent claws
- Industrial 2.5" x 10" cylinders
- Powder Coat Finish
- Many sizes available
Options
- Euro/global style mount
- Other Tractor mounts available
Specifications
Industrial Rod Grapples
Spec | HIRG 76 | HIRG 84 |
---|---|---|
Bucket Width | 76" | 84" |
Depth of Bucket | 42" | 42" |
Height of Bucket Back | 25" | 25" |
Height w/ Grapple closed | 32" | 32" |
Overall Grapple Width | 63" | 71" |
Grapple Width each | 21.5" | 21.5" |
Grapple Opening | 40.5" | 40.5" |
Weight | 1,230 lbs. | 1,330 lbs. |
Rod Size/Flat Bar Size | 1" x 1.5" | 1" x 1.5" |
Tine Spacing | 3" | 3" |
Cast Tooth w/ replaceable Tip | 10 | 11 |
